Bianbu Lichee Pi 3A Test Report
Test Environment
System Information
- System version: v3.0-minimal
- Download Links: https://archive.spacemit.com/image/k1/version/bianbu/v3.0/
- Reference Installation Document: https://wiki.sipeed.com/hardware/en/lichee/K1/lpi3a/1_intro.html
Hardware Information
- Lichee Pi 3A
- Power adapter
- A USB to UART Debugger
- A microSD Card (if flash to microSD)
- A Type-C cable for fastboot flash
Installation Steps
Flashing the Image (SD Card)
Please make sure to choose the file ending with .img.zip
After downloading and extracting the image, use dd to flash the image to the microSD card.
unzip bianbu-25.04-minimal-k1-v3.0-release-20250725114639.img.zip
sudo dd if=/path/to/bianbu-25.04-minimal-k1-v3.0-release-20250725114639.img of=/dev/your-device bs=1M status=progressFlashing the Image (eMMC)
Please make sure to choose the file ending without img
After downloading and extracting the image, use fastboot to flash the image to the eMMC.
unzip bianbu-25.04-minimal-k1-v3.0-release-20250725114639.zipHold the BOOT button while powering on/RST, to enter the fastboot mode. You shall see the dfu-device in your system.
Note: for the steps below,
sudomight be needed. Otherwisefastbootmight not pick up the board since it’s default USB VID/PID is not in the default udev rules.
❯ sudo fastboot devices
dfu-device DFU downloadfastboot stage factory/FSBL.bin
fastboot continue
# Wait for 1 sec
fastboot stage u-boot.itb
fastboot continue
# Wait for 1 sec
fastboot flash gpt partition_universal.json
fastboot flash bootinfo factory/bootinfo_emmc.bin
fastboot flash fsbl factory/FSBL.bin
fastboot flash env env.bin
fastboot flash opensbi fw_dynamic.itb
fastboot flash uboot u-boot.itb
fastboot flash bootfs bootfs.ext4
fastboot flash rootfs rootfs.ext4Logging into the System
Logging into the system via the serial port.
Default Username: root
Default Password: bianbu
Expected Results
The system should boot normally and allow login via the onboard serial port.
Actual Results
A Kernel Panic occurred during the boot process. The system is unable to boot. See the boot log below for details.
Boot Log
A KP/Kernel Panic occurred during the boot process, in spacemit_snd_sspa_pdev_probe.
Screen recording:
[ 6.477047] enter spacemit_snd_sspa_pdev_probe
[ 6.496425] Unable to handle kernel NULL pointer dereference at virtual address 0000000000000090
[ 6.505347] Oops [#1]
[ 6.507617] Modules linked in:
[ 6.510697] CPU: 3 PID: 1 Comm: swapper/0 Not tainted 6.6.63 #2.2.6.3
[ 6.517190] Hardware name: SiPEED LPi3A Board (DT)
[ 6.522013] epc : spacemit_snd_pcm_new+0x186/0x280
[ 6.526860] ra : spacemit_snd_pcm_new+0x172/0x280
[ 6.531666] epc : ffffffff80c7ac98 ra : ffffffff80c7ac84 sp : ffffffc800073900
[ 6.538953] gp : ffffffff82101ba8 tp : ffffffd900388000 t0 : ffffffff81a9e888
[ 6.546219] t1 : 0000000000000004 t2 : 0000000000000000 s0 : ffffffc800073990
[ 6.553496] s1 : 0000000000000000 a0 : 0000000000000000 a1 : 000000000000011b
[ 6.560771] a2 : 0000000000000000 a3 : 0000000000000000 a4 : ffffffd900388000
[ 6.568047] a5 : 0000000000000000 a6 : 0000000000002683 a7 : 0000000052464e43
[ 6.575333] s2 : 0000000000000002 s3 : fffffffffffff000 s4 : 0000000000000800
[ 6.582598] s5 : 0000000000000400 s6 : ffffffff815c9950 s7 : ffffffd902538540
[ 6.589864] s8 : ffffffd9051d4840 s9 : ffffffd904b23600 s10: 0000000000000002
[ 6.597129] s11: ffffffd9025385c0 t3 : ffffffffffffffff t4 : ffffffff82107fc8
[ 6.604395] t5 : 0000000000000040 t6 : ffffffd90507637d
[ 6.609738] status: 0000000200000120 badaddr: 0000000000000090 cause: 000000000000000d
[ 6.617710] [<ffffffff80c7ac98>] spacemit_snd_pcm_new+0x186/0x280
[ 6.623836] [<ffffffff80c64de8>] snd_soc_pcm_component_new+0x24/0x90
[ 6.630238] [<ffffffff80c6a46e>] soc_new_pcm+0x47e/0x600
[ 6.635585] [<ffffffff80c5af40>] snd_soc_bind_card+0x8c4/0xa5c
[ 6.641466] [<ffffffff80c5b1be>] snd_soc_register_card+0xe6/0xf8
[ 6.647537] [<ffffffff80c6a764>] devm_snd_soc_register_card+0x40/0x86
[ 6.654039] [<ffffffff80c7bdea>] asoc_simple_card_probe+0x16a/0x250
[ 6.660338] [<ffffffff808537c8>] platform_probe+0x52/0xb6
[ 6.665779] [<ffffffff80850e3c>] really_probe+0x8c/0x326
[ 6.671134] [<ffffffff80851138>] __driver_probe_device+0x62/0x112
[ 6.677277] [<ffffffff8085121e>] driver_probe_device+0x36/0xba
[ 6.683153] [<ffffffff8085140e>] __driver_attach+0x9a/0x1a2
[ 6.688754] [<ffffffff8084f022>] bus_for_each_dev+0x58/0xa6
[ 6.694370] [<ffffffff808508d6>] driver_attach+0x1a/0x22
[ 6.699714] [<ffffffff808500d6>] bus_add_driver+0xf6/0x1fe
[ 6.705233] [<ffffffff808522a8>] driver_register+0x40/0xda
[ 6.710762] [<ffffffff808534ec>] __platform_driver_register+0x1c/0x24
[ 6.717263] [<ffffffff80c7b988>] spacemit_snd_card_init+0x1a/0x22
[ 6.723398] [<ffffffff800027c2>] do_one_initcall+0x36/0x222
[ 6.729023] [<ffffffff81001422>] kernel_init_freeable+0x21c/0x286
[ 6.735169] [<ffffffff80ff66d8>] kernel_init+0x1e/0x116
[ 6.740446] [<ffffffff80fff192>] ret_from_fork+0xe/0x18
[ 6.745707] Code: b783 0d0c 6bdc cb89 4789 4481 13e3 f8f9 b783 108c (6bdc) ffb5
[ 6.753203] ---[ end trace 0000000000000000 ]---
[ 6.757872] Kernel panic - not syncing: Attempted to kill init! exitcode=0x0000000b
[ 6.765578] SMP: stopping secondary CPUs
[ 6.769528] ---[ end Kernel panic - not syncing: Attempted to kill init! exitcode=0x0000000b ]--- Test Criteria
Successful: The actual result matches the expected result.
Failed: The actual result does not match the expected result.
Test Conclusion
Test failed.
